6
Inserting the Battery
After charging the battery, insert it in the camera as described below.
1
Open the battery-chamber cover.
A Note
Be sure the camera is off before opening the
battery-chamber cover.
C Cautions
• Do not open the battery-chamber cover
when the camera is on. Failure to observe this
precaution could result in damage to image
files or memory cards.
• Do not use excessive force when handling the
battery-chamber cover.
2
Insert the battery.
Insert the battery
with the terminals first
and the orange stripe
aligned with the orange
battery latch. Slide the
battery into the camera,
keeping the battery
latch pressed to one
side as shown below. Confirm that the
battery is securely latched.
Battery latch
Orange stripe
C Caution
Insert the battery in the correct orientation. Do
NOT use force or attempt to insert the battery
upside down or backwards. The battery will
slide in easily in the correct orientation.
To Next Page
