Connecting external devices
50 10600664372, edition 2
Connecting external audio devices
Microphone port/Line In
Via the Microphone jack/Line In port you can connect an external microphone or audio devices to
your notebook.
i
If you attach an external microphone, the built-in microphone is disabled.
Headphones /SPDIF port
Via the Headphones/SPDIF Out port you can connect headphones, external loudspeakers or audio
devices with a digital optical input to your notebook.
i
If you attach headphones or external loudspeakers, the built-in loudspeakers are disabled.
If you purchase a cable from a retailer, please note the following information:
The headphones / SPDIF port on your notebook is a "3.5 mm jack socket".
If you want to connect headphones or loudspeakers, you will need a "3.5 mm jack plug".
If you want to connect audio devices with a digital optical input, you will need a "3.5 mm
jack plug/SPDIF".
Connectors Port Pin configuration
optical
Adjusting the volume
► Set the desired volume with the key combination Fn + F5 or Fn + F6 .
or
► To adjust the volume use the Windows volume control from the Start menu - Programs -
Accessories - Multimedia - Volume Control.
or
► Set the desired volume with the volume control.
