Fujitsu Siemens Computers AMILO Pi 1536 User Manual

Removing and installing components during servicing
54 10600664372, edition 2
Hard disk
The hard disk is the most important storage medium of your notebook. You can work considerably
faster and more efficiently if you copy applications and files from CDs/DVDs to your hard disk.
When the hard disk is accessed, the drive indicator lights up
.
Removing the hard disk
► Switch the notebook off and pull the power plug out of the mains socket.
► Close the LCD screen so that it locks into place.
► Disconnect all cables connected to the notebook.
► Turn your notebook over and place it on a sturdy, flat surface.
► Remove the battery (see "Removing battery").
1
1
2
► Remove the screws (1).
► Pull off the cover from the notebook in the direction of the arrow (2).
1
2
► Remove the screw (1).
► Lift the hard disk and remove the hard disk (2) from the hard disk compartment in the direction
of the arrow.
