Fujitsu Siemens Computers CELSIUS R630 User Manual

System expansions
A26361-K680-Z122-1-7619, Edition 1 29
Closing the casing
a
► Hook the side cover into the lower guide trail in the casing (1). Make sure that the side cover is
offset by approximately 2 cm (a).
► Engage the top edge of the side cover on the casing.
► Push the side cover as far as it will go in the direction of the arrow (2).
2
2
1
► Press the side cover onto the casing (1)
at the rear and tighten the two knurled
screws (2) with the other hand.

Fujitsu Siemens Computers CELSIUS R630 Specifications

General

Brand	Fujitsu Siemens Computers
Model	CELSIUS R630
Category	Desktop
Language	English
