Interfaces and connectors
8 - English A26361-D1534-Z120-2-7419
Pin assignment of internal ports
The pin assignment of some internal connections is shown in English in the following.
i
Some of the following connectors may be optional!
Fan
(system fan - supervised)
1
Pin Signal
1GND
2 Controlled Fan voltage (0 V, +6 V ... +12 V, max. 1 A)
or fix Fan voltage (+12 V, max. 1 A)
3 Fan sense
Processor power supply
power supply
13
Pin Signal Pin Signal
1 GND 3 +12V
2 GND 4 +12V
