Add-on modules / Upgrading
A26361-D1534-Z120-2-7419 English - 17
Monofunctional expansions cards:
Standard AGP and PCI expansion cards require a maximum of one interrupt, which is called the PCI
interrupt INT A. Expansion cards that do not require an interrupt can be installed in any desired slot.
Multifunctional expansion cards or expansion cards with integrated PCI-PCI bridge:
These expansion cards require up to four PCI interrupts: INT A, INT B, INT C, INT D. How many
and which of these interrupts are used is specified in the documentation provided with the card.
The assignment of the PCI interrupts to the PCI IRQ Lines is shown in the following table:
Onboard controller
USB 1,1 AC97
PCI slot (on
E383)
PCI INT
LINE
1st 2nd 3rd 4th
USB 2,0
SMBus
Audio
Modem
LAN
AGP
1 2
1 (A)A--A-----A- -
2 (B)-----AAA-B- -
3 (C)--A------- D C
4 (D)-A-------- C D
5 (E)--------A- - -
6 (F)---------- B A
7 (G)---------- A B
8 (H)----A----- - -
Use the first PCI slots that have a single PCI IRQ Line (no IRQ sharing). If you must use another
PCI slot with IRQ sharing, check whether the expansion card properly supports IRQ sharing with the
other devices on this PCI IRQ Line. The drivers of all cards and components on this PCI IRQ Line
must also support IRQ sharing.
