REFRIGERANT
SYSTEM DIAGRAM
2017.09.05
Thermistor (Compressor)
Compressor
4-way
Valve
Pressure
Check Valve
Pressure
sensor (High)
Pressure
Sensor (Low)
Pressure
switch
Muffler
Strainer Strainer
Expansion
Valve
Strainer
3-Way Valve
3-Way Valve
Accumulator
Refrigerant Pipe
12.7mm (1/2")
Refrigerant Pipe
25.4mm (1”)
Thermistor (Discharge)
Heat
Exchanger
Heat
Exchanger
Thermistor (Heat Exchanger Out)
Thermistor (Outdoor)
Cool
Refrigerant flow
Heat
11
OUTDOOR UNIT
Twin type
INDOOR UNIT
BRANCH
PIPE
BRANCH
PIPE
Thermistor (Room)
Thermistor (Pipe)
