Fujitsu AB G36LRTE Series Service Manual

OUTDOOR UNIT
AOYG90LRLA
Revision code : A
Revision code : None
2017.08.08 34
11
13
12
14
Pipe
cover
front
16
17
15
18
11 Top panel sub assy 9379416054
14 FUJITSU label 9380477006
13
Sevice panel sub assy 9380571056
12 Front panel sub assy 9380569046
Ref. Description
Parts number
15 Right panel sub assy 9380570059
17 Motor DC brushless
16 Propeller fan 9382350000
9603561017
18 Separate wall sub assy 9380567028 9380567035
