632017.07.28
34
35
31
32
33
INDOOR UNIT
CASSETTE
AUYG22LVLA
33
2 Stage Turbo Fan Assy
Cabinet A sub assy
9375480011
32 Fan Motor
Top plate assy
Motor wire holder
9602436019
31 Fan Motor Sub Assy 9375719012
34 Shaft Cap
Turbo fan washer
Cabinet B sub assy
9377807014
35 Washer Cover 9377811011
Ref. Description Part number
