14 Terminal 3P
INDOOR UNIT
CASSETTE
AUYG30LRLE
AUYG45LRLA
15 Terminal 3P
16 Thermistor Holder A
17 Thermistor Holder B
12 Power Supply PCB
18 Room Thermistor
19 Pipe Thermistor
2017.07.14 72
9306489045
11 PCB Holder 9378205017
9703345012
9378206014
9378330016
9707398366
13 Main PCB (AUYG30) 9710621130
13 Main PCB (AUYG45) 9710621376
9900822002
9900941017
Ref. Description
Part number
15
17
18
14
16
19
12
11
13
