2017.07.28 74
INDOOR UNIT
CASSETTE
AUYG30LRLE
AUYG45LRLA
32 Sensor Holder
33 Float Switch
36 Drain Pump Holder B
37 Pump Rubber
38 Drain Hose
39 Drain Port
9378329010
9900465018
31 Float Switch Sub Assy 9378593015
35 Pump Assy 9900464011
34 Drain Pump Sub Assy 9378592018
9375518011
9378426016
9378212015
9378213012
Ref. Description
Part number
35
39
38
34
37
36
33
32
31
