Fig. 5 Remote Control Unit
H SLEEP button
I MASTER CONTROL button
J SET TEMP./SET TIME buttons (
)
K Signal Transmitter
L TIMER button
M FAN CONTROL button
N START/STOP button
O AIR FLOW DIRECTION
VERTICAL SET button
P AIR FLOW DIRECTION
VERTICAL SWING button
Q AIR FLOW DIRECTION
HORIZONTAL SET button
R AIR FLOW DIRECTION
HORIZONTAL SWING button
S TIME ADJUST button
T ACL button
Rear side (Fig. 6)
U TEST RUN
● Touch the two metal contacts with a me-
tallic object to send the signal to perform
a test run.
● Perform a test run only when installing the
air conditioner. If the signal to perform a
test run is received during normal opera-
tion, the air conditioner’s thermostat will
malfunction.
● If the signal to perform a test run is re-
ceived during normal operation, the unit
will switch to the test operation mode and
the indoor unit’s OPERATION and TIMER
indicator lamps will flash simultaneously.
● To stop the test operation mode, press the
START/STOP button to stop the air condi-
tioner.
V Remote Control Unit Display (Fig. 7)
W Transmit Indicator
X Clock Display
Y Operating Mode Display
Z T imer Mode Display
[ Fan Speed Display
\ Temperature Set Display
] T imer Set Indicator
` Temperature Set Indicator
Fig. 1 Indoor Unit
1 Operating Control Panel (Fig. 2)
2 MANUAL AUTO button
3 Remote Control Signal Receiver
4 OPERATION Indicator Lamp (red)
5 TIMER Indicator Lamp (green)
6 SWING Indicator Lamp (orange)
(VERTICAL SWING)
7 SWING Indicator Lamp (orange)
(HORIZONTAL SWING)
●
If the TIMER indicator lamp flashes when
the timer is operating, it indicates that a
fault has occurred with the timer setting
(See page 16 Auto Restart).
8 Intake Grille (Fig. 3)
9 Air Filter
0 UP/DOWN Air Direction Flaps
A RIGHT/LEFT Air Direction Louvers
(behind UP/DOWN Air Direction Flaps)
B Drain Hose
C Power Supply Plug
D Power Supply Cord
Fig. 4 Outdoor Unit
The size of the outdoor unit varies according to
the model.
E Intake Port
F Outlet Port
G Pipe Unit
