Fig. 5 Remote Control Unit
C SLEEP Button
D MASTER CONTROL Button
E SET TEMP./SET TIME Buttons ( )
F Signal Transmitter
G TIMER Button
H FAN CONTROL Button
I START/STOP Button
J Battery compartment lid
Inside of the battery compartment lid (Fig. 6)
K AIR FLOW DIRECTION Button
L ENERGY SAVE Button
M CODE CHANGE (Slide Switch)
Switching the remote control unit code.
(Max. 4 units)
N TIME ADJUST Button
O TEST RUN Button
● This button is used when installing the air
conditioner and should not be used under
normal conditions as it will cause the air
conditioner’s thermostat function to oper-
ate incorrectly.
● If this button is pressed during normal op-
eration, the unit will switch to test opera-
tion mode, and the indoor unit’s OPERA-
TION indicator lamp and TIMER indicator
lamp will begin to flash simultaneously.
● To stop the test operation mode, either
press the TEST RUN button once again, or
press the START/STOP button to stop the
air conditioner.
P ACL Button
Q Remote Control Unit Display (Fig. 7)
R Transmit Indicator
S Clock Display
T Operating Mode Display
U Timer Mode Display
V Fan Speed Display
W Temperature Set Display
X Timer Set Indicator
Y Temperature Set Indicator
Fig. 1 Indoor Unit
1 Operating Control Panel (Fig. 2)
2 MANUAL AUTO button
3 Remote Control Signal Receiver
4 OPERATION Indicator Lamp (red)
5 TIMER Indicator Lamp (green)
6 SWING Indicator Lamp (orange)
(HORIZONTAL SWING)
7 SWING Indicator Lamp (orange)
(VERTICAL SWING)
● If the TIMER indicator lamp flashes when
the timer is operating, it indicates that a
fault has occurred with the timer setting
(See Page 17 Auto Restart).
8 Intake Grille
9 UP/DOWN Air Direction Flap
0 RIGHT/LEFT Air Direction Louvers
(behind UP/DOWN Air Direction Flap)
Fig. 4 Outdoor Unit
A Intake Port
B Outlet Port
