03-15
1. INTAKE GRILLE removal
Open the INTAKE GRILLE and remove the 3 mounting screws.
Remove the INTAKE GRILLE
INTAKE GRILLE
Tapping screw
Machine screw
Tapping screw
2. REPLACEMENT PARTS (For INDOOR UNIT)
2-1 PARTS LAYOUT DRAWING ( For ABU18/ 24RULX )
