Fujitsu ABU36RSLX - Page 81

03-22
3. SIDE COVER removal
Remove the 2 mounting screws.(Left side and Right side)
Remove the SIDE COVER A and B.
4. CONTROL BOX removal
Remove the 2 mounting screws.
Pull the CONTROL BOX downward.
1
1
2
2
1
1
2
2
1
2
SIDE COVER A (LEFT)
SIDE COVER B (LEFT)
Hook (2 places)
Hook (3 places)
CONTROL BOX
