Item no. Part no. Part name Service part
50 9379572019 Casing B ♦
51 9379570022 Sirocco fan assy ♦
52 9378593039 Float switch sub assy ♦
53 9379913003 Drain hose assy ♦
54 9378450141 Hose sub assy ♦
55 9379914062 Drain pump sub assy ♦
56 9711875082 Main PCB ♦
57 9710019005 2-way remote PCB ♦
58 9900896027 Terminal 5P (Remote) ♦
59 9900568009 Terminal 3P ♦
60 9710661020 Power supply PCB ♦
61 9900653019 Thermistor (Room) ♦
62 9900349035 Thermistor (Pipe) ♦
63 9379908047 Top panel sub assy ♦
64 9379571012 Casing U ♦
65 9379644006 Vibration-proof rubber assy ♦
66 9379047142 Motor sub assy ♦
67 9379971065 Sirocco fan sub assy ♦
68 9378038011 Joint assy ♦
69 9379570039 Sirocco fan assy ♦
70 9381052004 Shaft assy ♦
— 9710177057
→ire with connector
(CN46 on Main PCB—Terminal 5P [External input])
♦
— 9710171055
→ire with connector
(CN260 on Main PCB—CN262 on Power supply PCB)
♦
— 9710206047
→ire with connector
(CN261 on Main PCB—CN263 on Power supply PCB)
♦
— 9710343094
→ire with connector
(CN300 on Main PCB—Terminal 5P [Remote])
♦
— 9710703010
→ire with connector
(CN205 on Power supply PCB—Terminal 3P)
♦
2-2. Model: ADUH18LUAS1 - (02-9) - 2. Indoor unit parts list
