Item no. Part no. Part name Service part
1 9316193024 Base ♦
2 9316197015 Base cover A ♦
3 9316373013 Base cover B ♦
4 9316405011 Base bracket ♦
5 9316272019 Bracket panel ♦
6 9306628024 Bearing C assy ♦
7 9900720087 Terminal (3P) ♦
8 9316186019 Front panel R ♦
9 9316415171 Front panel total assy ♦
10 9316189027 Air filter ♦
11 9316418066 Intake grille assy ♦
12 9316458017 Rope assy ♦
13 9316474017 Air clean filter assy ♦
14 9318912005 Remote controller holder ♦
15 9332438871 Remote controller ♦
16 9316187016 Front panel L ♦
17 9900991005 Pipe thermistor ♦
18 9316091269 Evaporator total assy ♦
19 9316192027 Thermistor holder ♦
20 9316195011 Motor holder ♦
21 9602851003 Fan motor (MFD-14SXN) ♦
22 9316309012 Crossflow fan B assy ♦
23 9602850006 Fan motor (MFD-14TXN) ♦
24 9312004034 Crossflow fan assy ♦
25 9900975067 Room thermistor ♦
26
9711694034 Main PCB (09 model) ♦
9711694041 Main PCB (12 model) ♦
9711694058 Main PCB (14 model) ♦
a — Terminal bracket —
b — Cable bracket —
c — Terminal cover —
d — Front panel —
e — Terminal bracket (COM) —
f — Control box shield —
g — Control box cover —
h — Control box —
2-1. Models: AGHG09KVCB, AGHG12KVCB, and AGHG14KVCB - (02-3) - 2. Indoor unit parts list
