Item no. Part no. Part name Service part
1 9322556066 Top panel assy ♦
2 9900850012 Thermistor (Outdoor temp.) ♦
3 9377854025 Protective net ♦
4 9322327000 Thermistor holder ♦
5 9322552099 Cabinet right assy ♦
6 9322570024 Switch cover assy ♦
7 9323540033 Heater holder A ♦
8 9901059025 Base heater ♦
9 9901070013 Terminal ♦
10
9709685396 Main PCB (Service unit) (09 model) ♦
9709685402 Main PCB (Service unit) (12 model) ♦
9709685419 Main PCB (Service unit) (14 model) ♦
11 9900935054 Thermistor assy ♦
12 9322420039 Heat sink ♦
13 9323550049 Base assy ♦
14 9319157009 Emblem ♦
15 9384851000 Front panel assy ♦
16 9384273017 Fan guard ♦
17 9323541016 Heater holder B ♦
18 0700103070 Nut ♦
19 9322150004 Propeller fan ♦
20 9603601003 Fan motor ♦
21 9322553195 Motor bracket assy ♦
22 9317089661 Condenser total assy ♦
a — Separator —
b — Hair pin cushion —
3-1. Models: AOHG09KVCBN, AOHG12KVCBN, and AOHG14KVCBN - (02-9) - 3. Outdoor unit parts list
TECHNICAL DATA
AND PARTS LIST
TECHNICAL DATA
AND PARTS LIST
