Item no. Part no. Part name Service part
50
9322431004 Compressor assy (09 model) ♦
9810523006 Compressor assy (12, 14 models) ♦
51
9322445018 4-way valve assy (09 model) ♦
9383129063 4-way valve assy (12, 14 models) ♦
52 9970194023 Solenoid ♦
53
9322435002 Muffler (09 model) ♦
9322436009 Muffler (12, 14 models) ♦
54
9970095122 Expansion valve coil (09 model) ♦
9970173028 Expansion valve coil (12, 14 models) ♦
55
9322463005 Pulse motor valve assy (09 model) ♦
9322463029 Pulse motor valve assy (12, 14 models) ♦
56 9322474001 2-way valve assy ♦
57
9322475008 3-way valve assy (09 model) ♦
9322850010 3-way valve assy (12, 14 models) ♦
58 9324024006 S-insulator B (09 model) ♦
59 9322537003 S-insulator H (09 model) ♦
60 9324014007 S-insulator B (12, 14 models) ♦
61 9322847003 S-insulator F ♦
62 9322501004 S-insulator H (12, 14 models) ♦
63 9323045002 S-insulator V ♦
64 9322824004 S-insulator K (12, 14 models) ♦
65 9322386007 Rubber cushion ♦
66 9313437008 Special nut (M8) ♦
— 9900934040
Wire with connector (Fuse holder)
(P50 on Main PCB—Base heater)
♦
a — Valve bracket —
b — Muffler —
3-1. Models: AOHG09KVCBN, AOHG12KVCBN, and AOHG14KVCBN - (02-11) - 3. Outdoor unit parts list
