5-2. Outdoor unit
¢ Discharge temperature thermistor
Temperature (°C) Resistance (kΩ) Voltage (V)
-30.0 1,000.13 0.06
-25.0 720.28 0.09
-20.0 525.51 0.12
-15.0 388.12 0.16
-10.0 289.97 0.21
-5.0 219.01 0.28
0.0 167.12 0.36
5.0 128.77 0.46
10.0 100.14 0.57
15.0 78.56 0.71
20.0 62.14 0.87
25.0 49.54 1.04
30.0 39.79 1.23
35.0 32.19 1.44
40.0 26.22 1.66
45.0 21.49 1.88
50.0 17.73 2.12
55.0 14.71 2.35
60.0 12.27 2.57
65.0 10.29 2.79
70.0 8.68 3.00
75.0 7.35 3.19
80.0 6.26 3.38
85.0 5.35 3.54
90.0 4.59 3.69
95.0 3.96 3.83
100.0 3.43 3.96
105.0 2.98 4.07
110.0 2.60 4.17
115.0 2.28 4.26
120.0 2.00 4.33
5-2. Outdoor unit - (03-45) - 5. Thermistor resistance values
