OUTDOOR UNIT
AOYV09LAC
AOYV12LAC
PARTS
182008.05.08
1 Panel (Top)
Protective Net
3 Outdoor Thermistor
4 Teminal Cover
5 Cover (Switch)
6 Cabinet Right Assy
Parts numberDescriptionRef
9313989026
9313941024
9900210038
9315234018
9310979020
9313994082
2
8 Cabinet Left Assy 9313991012
14 Panel (Front) 9313806026
-- Emblem Rear 9315210012
-- Drain Pipe Assy 9303029022
13 Ring (Fan) 9313807016
11 Propeller Fan 9313808013
10 Motor Bracket Assy 9313990039
9 Motor DC Brushless 9602111015
1
2
3
4
5
6
8
11
9
10
10
13
14
