En-5
Fig. 5 Remote Controller
H
Signal Transmitter
I
MODE button
J
10°C HEAT button
K
ECONOMY button
L
SLEEP button
M
TIMER MODE button
N
FAN button
O
START/STOP button
P
SET TEMP. button (
/
)
Q
SET button
R
SWING button
S
TIMER SET ( / ) button
T
CLOCK ADJUST button
U
TEST RUN button
●
This button is used when installing the
conditioner, and should not be used under
normal conditions, as it will cause the air
conditioner’s thermostat function to operate
incorrectly.
●
If this button is pressed during normal op-
eration, the unit will switch to test operation
mode, and the Indoor Unit’s OPERATION
Indicator Lamp and TIMER Indicator Lamp
will begin to fl ash simultaneously.
●
To stop the test operation mode, press the
START/STOP button to stop the air condi-
tioner.
V
RESET button
W
Remote Controller Display (Fig. 6)
X
Temperature SET Display
Y
Operating Mode Display
Z
SLEEP Display
[
Transmit Indicator
\
Fan Speed Display
]
SWING Display
`
Timer Mode Display
a
Clock Display
Fig. 1 Indoor Unit
1
Operating Control Panel (Fig. 2)
2
Air Outlet Selection switch
3
MANUAL AUTO button
●
When the MANUAL AUTO button is pressed
in for more than 10 seconds, the forced
cooling operation will start.
●
The forced cooling operation is used at the
time of installation.
Only for authorized service personnel's use.
●
When the forced cooling operation starts by
any chance, press the START/STOP button
to stop the operation.
4
Indicator (Fig. 3)
5
Remote Control Signal Receiver
6
OPERATION Indicator Lamp (green)
7
TIMER Indicator Lamp (orange)
●
If the TIMER indicator lamp flashes when
the timer is operating, it indicates that a fault
has occurred with the timer setting (See
page 19 “AUTO Restart”.)
8
ECONOMY Indicator Lamp (green)
9
Intake Grille (Fig. 4)
0
Front Panel
A
Air Filter
B
Airfl ow Direction Louver
C
Damper
D
Right-Left Louver
(behind Airflow Direction Louver and
Damper)
E
Drain Hose
F
Air Cleaning Filter
G
Rope
