03-24
Troubleshooting 17
Detective details:
Detective actuators:
Forecast of cause:
IPM error
Indicate or Display:
Indoor unit
Operation lamp: 6 times Flash,
Timer lamp : 5 times Flash
Wired remote
Error code : [E : 65]
n
: n times blinking
: Light ON: Light OFF
Mode Error
2 6
5
Outdoor unit (AOUG36/48LMAS1)
Test 3 : Check outdoor fan
OK
OK
Test 6 : Replace main PCB
OK
OK
Test 1 : Check connections of outdoor unit electrical
components
1. Defective connection of electric
components
2. Outdoor Fan Operation failure
3. Outdoor heat-exchanger clogged
4. Compressor failure
5. Main PCB failure
6. Transistor PCB failure
Check if connector is removed.
Check if the terminal connection is loose.
Check erroneous connection.
Check if cable is open.
>>Upon correcting the removed connector or miss-wiring,
reset the power.
Test 2 : Check outdoor fan, heat-exchanger
Is there anything obstructing the air distribution circuit?
Is there any clogging of Outdoor Heat Exchanger?
Is the Fan rotating by hand when operation is off ?
>> If the Fan Motor is locked, replace it.
Check Outdoor Fan Motor. (Refer to Troubleshooting 26)
>> If the Fan Motor is failure, replace it.
Test 4 : Check compressor
Check Compressor. (PARTS INFORMATION 2)
If Test 1 - 5 do not improve the symptom, change Main PCB.
OK
Test 5 : Check transistor PCB
Check Transistor PCB
>>If Transistor PCB is abnormal, replace it.
Outdoor unit main PCB
Compressor
Transistor PCB
①
When more than normal operating
current to IPM in main PCB flows,
the compressor stops.
the compressor stops.
③
If
①
and
②
repeats 5 times,
the compressor stops permanently.
②
After the compressor restarts.
If the same operation is repeated
within 40sec,
A B FEDC
To Next Page
