Fujitsu AO*54LJBYL User Manual

08-09
OUTDOOR UNIT
PROTECTION FORM
AO*24LMAKL
FUSE
(SIDE OF POWER SUPPLY TERMINAL)
- 25A 250V
- 3.15A 250V
- 5A 250V
FAN MOTOR PROTECTION THERMAL PROTECTOR 150±5°C OFF
PRESSURE SWITCH 4.2MPa
THERMAL SWITCH
OFF 120±5°C
ON 85±7°C
FUSE ON MAIN PCB
COMPRESSOR PROTECTION
PROTECTION FORM AO*30LMAWL AO*36LMAWL
FUSE (SIDE OF POWER SUPPLY TERMINAL) - 25A 250V 25A 250V
FUSE (SIDE OF INDOOR UNIT) - 10A 250V 10A 250V
- 3.15A 250V 3.15A 250V
- 5A 250V 5A 250V
FAN MOTOR PROTECTOR THERMAL PROTECTOR 150±5°C OFF 150±5°C OFF
HIGH PRESSURE PROTECTION PRESSURE SWITCH
OFF:4.2±0.1MPa
ON:3.2±0.15MPa
OFF:4.2±0.1MPa
ON:3.2±0.15MPa
DISCHARGE THERMISTOR THERMAL PROTECTOR
OFF:120±5°C
ON:80±5°C
OFF:120±5°C
ON:80±5°C
COMPRESSOR THERMISTOR THERMAL PROTECTOR
OFF:130±5°C
ON:80±5°C
OFF:130±5°C
ON:80±5°C
FUSE ON MAIN PCB
PROTECTION FORM AO*45LJBYL AO*54LJBYL
FUSE
(SIDE OF INDOOR UNIT TERMINAL)
- 10A 250V 10A 250V
- 3.15A 250V 3.15A 250V
- 5A 250V 5A 250V
FAN MOTOR PROTECTOR THERMAL PROTECTOR 150±5°C OFF 150±5°C OFF
HIGH PRESSURE PROTECTION PRESSURE SWITCH
OFF:4.2±0.1MPa
ON:3.2±0.15MPa
OFF:4.2±0.1MPa
ON:3.2±0.15MPa
DISCHARGE THERMISTOR THERMAL PROTECTOR
OFF:120±5°C
ON:80±5°C
OFF:120±5°C
ON:80±5°C
COMPRESSOR THERMISTOR THERMAL PROTECTOR
OFF:130±5°C
ON:80±5°C
OFF:130±5°C
ON:80±5°C
FUSE ON MAIN PCB
8-4. SAFETY DEVICE
