Main PCB
Active Filter Module
Compressor
4-way valve
PTC Thermistor
Thermistor
(Discharge temp.)
1. REPLACEMENT PARTS (For OUTDOOR UNIT)
1-1 For AO*18/ 24LMAKL
1-1-1 PARTS LAYOUT DRAWING
10-01
Fan motor
Fan
Heat Exchanger
Accumulator
Pressure SW
Coil (Expansion valve)&
Expansion valve
Solenoid
