Main PCB
Filter PCB
D,Power (Bridge)
Active Filter Module
Thermistor (Heat sink)
Fan motor
Fan
Heat Exchanger
Accumulator
Compressor
4-way valve
Solenoid
Thermistor
(Compressor temp.)
Thermistor
(Discharge temp.)
Choke coil
1-3-1 PARTS LAYOUT DRAWING
10-21
1-3 For AO*45/ 54LJBYL
