Fujitsu AO*54LJBYL User Manual

10-14
BIND
W12 / "P" (Yellow)
W13 / "N1"(Blue)
CN407
CN407
" P " (Yellow)
" N1 " (Blue)
" - " (Black)
" + " (Red)
" L1 " (White)
Twist 4 times or more 2 turn the Wire this way
" L2 " (Brown)
Thermistor (Heat sink)
Remove the connector and cords.
VIEW - F
DETAIL
