7. LOUVER CONTROL
1. VERTICAL LOUVER CONTROL
Each time the button is pressed,
the air direction range will change as follows:
Use the air direction adjustments within the ranges shown above.
The vertical airflow direction is set automatically as shown, in accordance with the type of operation selected.
Cooling / Dry mode : Horizontal flow
Heating mode : Downward flow
During AUTO mode operation, for the fi rst minute after beginning operation, airflow will be upward ;
the air direction cannot be adjusted during this period.
During Heating mode operation, airflow will be upward when the temperature of the air issued
from the indoor is low.
(Function and Operation Range)
(Fig 9: Air Direction Range)
3. SWING OPERATION
When the swing signal is received from the remote controller, the vertical louver starts to swing.
(Swinging Range)
When the indoor fan is either at S-lo or Stop mode, the swinging operation is interrrupted
and the louver stops at the memorized position.
01-07
The Remote controller's display does
not change.
Move the Right-Left louvers to adjust airfow in the direction you prefer.
2. ADJUST THE RIGHT-LEFT LOUVERS
To select Vertical Airflow Swing Operation
To select Horizontal Airflow Swing Operation
(No function)
