2. HEATING OPERATION
( Table 3 : Compressor frequency range )
01-02
3. DRY OPERATION
The compressor frequency shall change according to the temperature, set temperature,
and room temperature variation which the room temperature sensor of the indoor unit body has
detected as shown in the Table 4.
However, after the compressor is driven, the outdoor unit shall run at operation frequency of
51rps (9RLFF), 51rps (12RLFF), 52rps (15RLFF) for a minute.
( Table 4 : Compressor frequency in Dry mode)
Operating
frequency
26rps
18rps
0rps
AOU
9RLFF
X zone
J zone
Y zone
Operating
frequency
J zone
Y zone
X zone 26rps
18rps
0rps
AOU
12RLFF
Operating
frequency
J zone
Y zone
X zone 24rps
16rps
0rps
AOU
15RLFF
A sensor (room temperature thermistor) built in the indoor unit body will usually perceive
difference or variation between a set temperature and present room temperature, and
controls the operation frequency of the compressor.
* If the room temperature is lower by 6°F(3°C) than a set temperature, the compressor operation
frequency will attain to maximum performance.
* If the room temperature is higher 5°F(2.5°C) than a set temperatire, the compressor will be
stopped.
* When the room temperature is between +5°F(+2.5°C) to -6°F(-3°C) of the setting temperature,
the compressor frequency is controlled within the range shown in Table 3.
Ts+1°F
(Ts+0.5°C)
Ts-1°F
(Ts-0.5°C)
Ts-3°F
(Ts-1.5°C)
Ts+3°F
(Ts+1.5°C)
( Fig.2 : Compressor Control based on Room Temperature )
Room Room
temperature temperature
X zone
J zone
Y zone
Minimum
frequency
Maximum
frequency
AOU9RLFF
AOU12RLFF
AOU15RLFF
16rps 119rps
16rps 140rps
Upper & Lower
Upper
Upper & Lower
Upper
Air flow
