DIMENSIONS
2013.10.04 2
OUTDOOR UNIT
11-7/16 in. (290) 31-1/8 in. (790 mm)
21-1/4 inch (540 mm)
24-7/16 in. (620 mm)
INDOOR UNIT
Drain hose length : 600 mm
Drain pipe diameter
Inside : 14.2 mm
Outside : 16.2 mm
29-1/8 in. (740 mm)
7-7/8 (200)
23-5/8 in. (600 mm)
