12-2. Cassette grille
Exterior Part name Model name Summary
Cassette grille UTG-CCGF
When using this cassette grille, the
ceiling openings become smaller.
Cassette grille UTG-CCGFG
This cassette grille can be installed
appropriately on the grid type ceiling
common in the office.
12-3. Others
Exterior Part name Model name Summary
External
connect kit
UTY-XWZX
Use to connect with various peripheral
devices and air conditioner PCB.
Air outlet shutter
plate
UTR-YDZB
Installed at the air outlet when 3-
directions mode is performed.
Fresh-air intake
kit
UTZ-VXAA
By attaching Fresh-air intake kit to the
indoor unit, it can be taken in fresh air
of up to 10% of “high” air volume of
the indoor unit.
Insulation for
high humidity
UTZ-KXGC
Install when the under-roof condition is
expected to be the humidity of over
80% and the temperature of over
86 °F(30 °C).
- 44 -
12-2. Cassette grille 12. Optional parts
CASSETTE TYPE
AUU09-18RLF
CASSETTE TYPE
AUU09-18RLF
