Fujitsu AOU18RLXFW Design & Technical Manual

- (01 - 10) -
WALL MOUNTED TYPE ASU18-24RLF WALL MOUNTED TYPE ASU18-24RLF
CAPACITY TABLE6.
COOLING CAPACITY6-1.
MODEL

: ASU18RLF
AFR : Air ow rate (CFM)
TC : Total capacity (kBTU)
SHC : Sensible Heat capacity (kBTU)
IP : Input Power (kW)
AFR : Air ow rate (m
3
/min)
TC : Total capacity (kW)
SHC : Sensible Heat capacity (kW)
IP : Input Power (kW)
MODEL

: ASU24RLF
AFR : Air ow rate (CFM)
TC : Total capacity (kBTU)
SHC : Sensible Heat capacity (kBTU)
IP : Input Power (kW)
AFR : Air ow rate (m
3
/min)
TC : Total capacity (kW)
SHC : Sensible Heat capacity (kW)
IP : Input Power (kW)
AFR 541
Indoor temperature
°FDB 64 70 75 80 85 90
°FWB 54 60 63 67 71 73
Outdoor temperature
°FDB TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP
59 17.36 11.16 0.78 19.34 11.23 0.79 21.31 12.24 0.80 21.97 13.22 0.81 23.29 13.17 0.81 24.61 14.03 0.82
67 16.66 10.86 0.92 18.56 10.93 0.93 20.46 11.92 0.95 21.09 12.87 0.95 22.36 12.82 0.96 23.63 13.66 0.97
77 15.92 10.55 1.06 17.73 10.61 1.07 19.54 11.57 1.09 20.15 12.50 1.09 21.35 12.45 1.11 22.56 13.26 1.12
87 15.11 10.22 1.19 16.83 10.28 1.21 18.55 11.21 1.23 19.12 12.10 1.23 20.27 12.05 1.25 21.42 12.84 1.26
95 14.23 9.86 1.30 15.85 9.92 1.32 17.47 10.82 1.34 18.00 11.68 1.35 19.10 11.64 1.36 20.18 12.39 1.38
104 13.57 9.60 1.45 15.11 9.65 1.47 16.66 10.53 1.49 17.17 11.37 1.50 18.20 11.32 1.51 19.23 12.06 1.53
115 12.39 9.13 1.62 13.80 9.19 1.65 15.21 10.02 1.67 15.68 10.82 1.68 16.62 10.78 1.70 17.56 11.48 1.72
AFR 15.3
Indoor temperature
°CDB 17.8 21.1 23.9 26.7 29.4 32.2
°CWB 12.2 15.6 17.7 19.4 21.7 22.8
Outdoor temperature
°CDB TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP
15.0 5.09 3.27 0.78 5.67 3.29 0.79 6.25 3.59 0.80 6.44 3.88 0.81 6.83 3.86 0.81 7.21 4.11 0.82
19.4 4.88 3.18 0.92 5.44 3.20 0.93 6.00 3.49 0.95 6.18 3.77 0.95 6.55 3.76 0.96 6.92 4.00 0.97
25.0 4.66 3.09 1.06 5.20 3.11 1.07 5.73 3.39 1.09 5.90 3.66 1.09 6.26 3.65 1.11 6.61 3.89 1.12
30.6 4.43 2.99 1.19 4.93 3.01 1.21 5.44 3.28 1.23 5.61 3.55 1.23 5.94 3.53 1.25 6.28 3.76 1.26
35.0 4.17 2.89 1.30 4.65 2.91 1.32 5.12 3.17 1.34 5.28 3.42 1.35 5.60 3.41 1.36 5.91 3.63 1.38
40.0 3.98 2.81 1.45 4.43 2.83 1.47 4.88 3.09 1.49 5.03 3.33 1.50 5.34 3.32 1.51 5.64 3.54 1.53
46.1 3.63 2.68 1.62 4.04 2.69 1.65 4.46 2.94 1.67 4.59 3.17 1.68 4.87 3.16 1.70 5.15 3.37 1.72
AFR 659
Indoor temperature
°FDB 64 70 75 80 85 90
°FWB 54 60 63 67 71 73
Outdoor temperature
°FDB TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP
59 18.62 11.32 0.82 20.74 11.39 0.83 22.86 12.42 0.84 23.57 13.41 0.85 24.99 13.36 0.85 26.40 14.23 0.86
67 17.91 11.06 0.95 19.95 11.13 0.97 21.99 12.14 0.98 22.67 13.11 0.99 24.03 13.06 1.00 25.39 13.91 1.01
77 19.30 11.57 1.37 21.50 11.64 1.39 23.70 12.69 1.41 24.43 13.71 1.42 25.90 13.65 1.43 27.37 14.54 1.44
87 18.37 11.23 1.53 20.46 11.30 1.55 22.56 12.32 1.58 23.25 13.30 1.58 24.65 13.25 1.60 26.04 14.12 1.61
95 17.36 10.87 1.70 19.34 10.93 1.72 21.31 11.93 1.75 22.00 12.88 1.76 23.29 12.83 1.78 24.61 13.66 1.80
104 16.23 10.48 1.86 18.07 10.54 1.89 19.92 11.50 1.92 20.54 12.42 1.93 21.77 12.37 1.95 23.00 13.17 1.97
115 12.35 9.23 1.56 13.76 9.28 1.58 15.17 10.12 1.61 15.64 10.93 1.61 16.58 10.89 1.63 17.52 11.60 1.65
AFR 18.7
Indoor temperature
°CDB 17.8 21.1 23.9 26.7 29.4 32.2
°CWB 12.2 15.6 17.7 19.4 21.7 22.8
Outdoor temperature
°CDB TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP
15.0 5.46 3.32 0.82 6.08 3.34 0.83 6.70 3.64 0.84 6.91 3.93 0.85 7.32 3.91 0.85 7.74 4.17 0.86
19.4 5.25 3.24 0.95 5.85 3.26 0.97 6.44 3.56 0.98 6.64 3.84 0.99 7.04 3.83 1.00 7.44 4.08 1.01
25.0 5.66 3.39 1.37 6.30 3.41 1.39 6.95 3.72 1.41 7.16 4.02 1.42 7.59 4.00 1.43 8.02 4.26 1.44
30.6 5.38 3.29 1.53 6.00 3.31 1.55 6.61 3.61 1.58 6.82 3.90 1.58 7.22 3.88 1.60 7.63 4.14 1.61
35.0 5.09 3.19 1.70 5.67 3.20 1.72 6.25 3.50 1.75 6.44 3.77 1.76 6.83 3.76 1.78 7.21 4.00 1.80
40.0 4.76 3.07 1.86 5.30 3.09 1.89 5.84 3.37 1.92 6.02 3.64 1.93 6.38 3.62 1.95 6.74 3.86 1.97
46.1 3.62 2.70 1.56 4.03 2.72 1.58 4.45 2.97 1.61 4.58 3.20 1.61 4.86 3.19 1.63 5.13 3.40 1.65
