Fujitsu AOU18RLXFW Design & Technical Manual

- (01 - 06) -
WALL MOUNTED TYPE ASU18-24RLF WALL MOUNTED TYPE ASU18-24RLF
SPECIFICATIONS3.
Type
WALL MOUNTED
INVERTER HEAT PUMP
Model name ASU18RLF ASU24RLF
Power source 208/230V ~ 60Hz
Available voltage range 187-253V ~ 60Hz
Capacity
Cooling
Rated
kW 5.28 6.44
BTU/h 18,000 22,000
Min-Max
kW 2.05 - 6.74 2.90 - 8.00
BTU/h 7,000 - 23,000 9,900 - 27,300
Heating
Rated
kW 6.30 8.10
BTU/h 21,600 27, 6 0 0
Min-Max
kW 2.05 - 8.50 2.20 - 10.61
BTU/h 7,000 - 29,000 7,500 - 36,200
Input power
Cooling
Rated
kW
1.35 1.76
Max 3.01 3.42
Heating
Rated 1.80 2.38
Max 3.23 3.53
Current
Cooling
Rated
A
6.2 7.9
Max 13.5 15.0
Heating
Rated 8.0 10.5
Max 14.5 15.5
EER Cooling
kW/kW 3.90 3.66
BTU/hW 13.3 12.5
COP Heating
kW/kW 3.50 3.40
BTU/hW 12.0 11.6
SEER Cooling BTU/hW 19.2 18.0
HSPF Heating BTU/hW 10.0 10.0
POWER FACTOR
Cooling
%
95 97
Heating 98 99
Moisture removal pints/h (l/h) 5.9 (2.8) 6.3 (3.0)
Fan
Airow
rate
Cooling
High
CFM
(m
3
/h)
541 (920) 659 (1,120)
Med 435 (740) 530 (900)
Low 365 (620) 435 (740)
Quiet 306 (520) 365 (620)
Heating
High 541 (920) 677 (1,150)
Med 435 (740) 530 (900)
Low 365 (620) 435 (740)
Quiet 318 (540) 365 (620)
Type × Q'ty Cross ow fan × 1
Motor output W 64 64
Sound pressure level
Cooling
High
dB(A)
43 49
Med 37 42
Low 33 37
Quiet 28 33
Heating
High 44 49
Med 37 42
Low 33 37
Quiet 28 33
Heat exchanger type
Dimensions
(H × W × D)
in. (mm)
Main:15-7/8 x 33-3/4 x 1-1/16 (378×832×26.6)
Sub: 3-5/16 x 33-3/4 x 17/32 (84×832×13.3)
Fin pitch FPI Main:21, Sub:18
Rows x Stages Main:2×18, Sub:1×4
Pipe type Copper
Fin type Aluminium
Enclosure
Material Polystyrene
Color
WHITE
Approximate color of MUNSELL N9.25/
Dimensions
( H×W×D )
Net
mm 320×998×228
inch 12-5/8×39-1/4×9
Gross
mm 319×1090×429
inch 12-3/5×42-15/16×16-7/8
Weight
Net
lbs. (kg)
31 (14)
Gross 40 (18)
Connection pipe
Size
Liquid
in. (mm)
Ø 3/8 (Ø 9.52)
Gas Ø 5 /8 (Ø 15.88)
Method Flare
Operation range
Cooling
°F (°C) 64 to 90 (18 to 32)
%RH 80 or less
Heating °F (°C) 88 (30) or less
Remote controller type Wireless
Drain pipe
Material PVC
Size
mm
(Reference in.)
Outer diameter: 28 (1-3/32)
Inner diameter: 16 (5/8) .
Note :
Specications are based on the following conditions.
Cooling : Indoor temperature of 80°F (26.67°C)DB / 67°F (19.44°C)WB, and outdoor temperature of 95°F (35°C)DB / 75°F (23.9°C)WB.
Heating : Indoor temperature of 70°F (21.11°C)DB / 59°F (15°C)WB, and outdoor temperature of 47°F (8.33°C)DB / 43°F (6.11°C)WB.
Pipe length : 24.6ft(7.5m) [Outdoor unit - Indoor unit], Height difference : 0ft. (0m) [Outdoor unit - Indoor unit]
