Fujitsu AOU18RLXFW - Heating Operation

- (01 - 02) -
WALL MOUNTED TYPE ASU18-24RLF WALL MOUNTED TYPE ASU18-24RLF
Power diffuser
z
Adoption of large power diffuser
16
Outside air conditions:35.6
o
F 60%
( F)
Operation contents: Heating,
Set temperature (Max set temp)
o
8492 90 88 86
86
o
F , Air flow Hi,
Vertical flap : Downward
Horizontal flap : Center
7
3
0
10 20 30 40
(ft)
(ft)
Power diffuser
(full open)
46
o
“Strong vertical air ow” provides
powerful oor level heating.
“Healthy horizontal air ow” does not blow
cool air directly at the occupants in the room.
Power diffuser
Outside air conditions: 95
o
F 40%
( F)
Operation contents: Cooling,
Set temperature (Min set temp)
65
o
o
F , Air flow Hi,
6559 61 63
7
3
0
10 20 30 40
(ft)
(ft)
Vertical flap : Upward
Horizontal flap : Center
Low ambient outdoor temperature design (24Model)
z
Low ambient outdoor temperature design
Cooling
0 to 115 °F
Heating
0 to 75 °F
Corresponds to maximum 164feet (50m) long piping
