Fujitsu AOU30RLXB - Indoor Unit Dimensions and Installation

-
(
01 - 07
)
-
WALL MOUNTED TYPE
ASU18-36RL
WALL MOUNTED TYPE ASU18-36RL
DIMENSIONS4.
MODEL

: ASU18RLB, ASU24RLB, ASU30RLXB, ASU36RLXB
Unit : in (mm)
ASU18RLB
ASU24RLB
ASU30RLXB
ASU36RLXB

Refrigerant pipe
flare connection
Liquid
Ø 1/4 in. (Ø 6.35 mm) Ø 3/8 in. (Ø 9.52 mm)

Gas
Ø 1/2 in. (Ø 12.70 mm) Ø 5/8 in. (Ø15.88 mm)

Drain hose
connection
Drain hose
I.D. Ø 15/32 in. (Ø 12 mm) , O.D. Ø 5/8 in. (Ø 16 mm)
Drain hose : L=26-3/8 in. (670mm)
39-5/16 (998)
17-1/4 (438)
15-5/8 (397)
12-5/8 (320): Unit size
2 (51)
2 (51)
13/16 (20)
2-5/8 (67)1-1/8 (28)
35-9/16 (903)
Ø 3-1/8 (80) hole
39-5/16 (998): Unit size
Outline of unit
Piping inlet
Unit center
9 (228)
12-5/8
(
320
)
20-1/2 (520)
20-1/2 (520)
23-1/4 (590)
28-3/8 (721)
Ø 3-1/8 (80) hole
Piping inlet
11/16 (17)
1 (25)
ø1-1/4 (32)
ø5/8 (16)
ø1/8 (12)
7/16 (11)
