WALL MOUNTED TYPE
ASU18-36RL
WALL MOUNTED TYPE ASU18-36RL
Power diffuser

Adoption of large power diffuser
16
Outside air conditions:35.6
o
F 60%
(F)
Operation contents: Heating,
Set temperature (Max set temp)
o
8492 90 88 86
86
o
F , Air flow Hi,
Vertical airflow direction louver : Downward
Horizontal airflow direction louver : Center
7
3
0
10 20 30 40
(ft)
(ft)
Power diffuser
(full open)
0
6
7
3
3
(f
t
)
46
o
“Strong vertical air flow” provides
powerful floor level heating.
“Healthy horizontal air flow” does not blow
cool air directly at the occupants in the room.
Power diffuser
Outside air conditions: 95
o
F 40%
( F)
Operation contents: Cooling,
Set temperature (Min set temp)
65
o
o
F , Air flow Hi,
6559 61 63
7
3
0
10 20 30 40
(ft)
(ft)
Vertical airflow direction louver : Upward
Horizontal airflow direction louver : Center
Low ambient outdoor temperature design

Cooling
14 to 115
°F
Heating
5 to 75
Corresponds to long piping

18, 24 Model
65 (20)
ft. (m)
30, 36 Model
164 (50)
