As shown in Fig.4, pull out the wires.
As shown in Fig.5, pull out the wires and fix them.
03-10
W16 (Red)
W17 (Black)
Thermistor
(Heat sink)
CN407
W303 (Black)
W304 (White)
W305 (Red)
Fig. 4
Fig. 5
W12 (Yellow)
W13 (Blue)
W17 (Black)
W16 (Red)
W303 (Black)
W304 (White)
W305 (Red)
Hook (2 places)
