03-16
2. COVER PLATE (RIGHT) removal
Remove the 1 mounting screw.
Remove the COVER PLATE (RIGHT).
COVER PLATE (RIGHT)
3. COVER PLATE (LEFT) removal
Remove the 1 mounting screw.
Remove the COVER PLATE (LEFT).
COVER PLATE (LEFT)
Hook (2 places)
Hook (2 places)
Hook (2 places) Hook (2 places)
