03-17
4. CONTROL BOX removal
Remove the 4 mounting screw.
CONTROL BOX
CONTROL BOX
Do not remove the screws.
If the stays are removed,
the
CONTROL BOX will fall.
A
VIEW - A
Pull out the CONTROL BOX.
CONTROL BOX
