Fujitsu AOUG48LMAS1 Design & Technical Manual

3-2. Heating capacity
NOTE: Values mentioned in the table are calculated based on the maximum capacity.
¢ Model: AMUG24LMAS
AFR CFM 800
Indoor temperature
°FDB 60 65 70 72 75
Outdoor temperature
°FDB °FWB
TC IP TC IP TC IP TC IP TC IP
kBtu/h kW kBtu/h kW kBtu/h kW kBtu/h kW kBtu/h kW
-5 -7 18.76 3.19 18.37 3.20 18.10 3.20 18.04 3.43 17.96 3.48
5 3 20.64 3.19 19.72 3.20 19.80 3.22 20.13 3.41 20.95 3.48
14 12 20.82 3.17 20.97 3.25 21.50 3.28 21.29 3.41 21.39 3.48
23 19 23.22 3.20 23.87 3.28 23.95 3.35 23.90 3.42 23.51 3.49
32 28 26.52 3.28 27.10 3.34 26.81 3.41 26.67 3.44 25.97 3.49
41 37 30.74 3.42 30.68 3.44 30.09 3.45 29.59 3.47 28.76 3.49
47 43 34.03 3.54 33.22 3.52 32.40 3.47 31.58 3.50 30.79 3.49
50 47 35.86 3.61 34.59 3.58 33.79 3.47 32.66 3.52 31.87 3.49
59 50 41.90 3.85 38.85 3.75 37.91 3.48 35.90 3.58 35.31 3.50
AFR
m
3
/h
1,359
Indoor temperature
°CDB 15.6 18.3 21.1 22.2 23.9
Outdoor temperature
°CDB °CWB
TC IP TC IP TC IP TC IP TC IP
kW kW kW kW kW
-20.6 -21.7 5.50 3.19 5.38 3.20 5.30 3.20 5.29 3.43 5.26 3.48
-15 -16.1 6.05 3.19 5.78 3.20 5.80 3.22 5.90 3.41 6.14 3.48
-10 -11.1 6.10 3.17 6.14 3.25 6.30 3.28 6.24 3.41 6.27 3.48
-5 -7.2 6.81 3.20 6.99 3.28 7.02 3.35 7.00 3.42 6.89 3.49
0 -2.2 7.77 3.28 7.94 3.34 7.86 3.41 7.82 3.44 7.61 3.49
5 2.8 9.01 3.42 8.99 3.44 8.82 3.45 8.67 3.47 8.43 3.49
8.3 6.1 9.97 3.54 9.74 3.52 9.50 3.47 9.26 3.50 9.02 3.49
10 8.3 10.51 3.61 10.14 3.58 9.90 3.47 9.57 3.52 9.34 3.49
15 10 12.28 3.85 11.39 3.75 11.11 3.48 10.52 3.58 10.35 3.50
¢ Model: AMUG30LMAS
AFR CFM 870
Indoor temperature
°FDB 60 65 70 72 75
Outdoor temperature
°FDB °FWB
TC IP TC IP TC IP TC IP TC IP
kBtu/h kW kBtu/h kW kBtu/h kW kBtu/h kW kBtu/h kW
-5 -7 22.58 3.23 22.11 3.24 21.70 3.24 21.70 3.48 21.62 3.52
5 3 23.28 3.24 22.19 3.24 22.20 3.26 22.64 3.46 23.58 3.53
14 12 25.06 3.21 25.23 3.30 25.86 3.33 25.61 3.45 25.75 3.53
23 19 27.95 3.24 28.72 3.32 28.81 3.40 28.75 3.46 28.31 3.53
32 28 31.92 3.33 32.61 3.38 32.26 3.46 32.08 3.49 31.27 3.54
41 37 37.00 3.47 36.91 3.48 36.21 3.50 35.59 3.52 34.62 3.54
47 43 40.95 3.59 39.98 3.57 39.00 3.52 38.03 3.55 37.05 3.54
50 47 43.16 3.66 41.63 3.63 40.66 3.52 39.30 3.57 38.37 3.54
59 50 50.43 3.91 46.75 3.80 45.61 3.53 43.19 3.63 42.52 3.55
AFR
m
3
/h
1,478
Indoor temperature
°CDB 15.6 18.3 21.1 22.2 23.9
Outdoor temperature
°CDB °CWB
TC IP TC IP TC IP TC IP TC IP
kW kW kW kW kW
-20.6 -21.7 6.62 3.23 6.48 3.24 6.36 3.24 6.36 3.48 6.34 3.52
-15 -16.1 6.82 3.24 6.50 3.24 6.51 3.26 6.63 3.46 6.91 3.53
-10 -11.1 7.35 3.21 7.39 3.30 7.58 3.33 7.51 3.45 7.55 3.53
-5 -7.2 8.19 3.24 8.42 3.32 8.44 3.40 8.43 3.46 8.30 3.53
0 -2.2 9.36 3.33 9.56 3.38 9.45 3.46 9.40 3.49 9.16 3.54
5 2.8 10.84 3.47 10.82 3.48 10.61 3.50 10.43 3.52 10.15 3.54
8.3 6.1 12.00 3.59 11.72 3.57 11.43 3.52 11.14 3.55 10.86 3.54
10 8.3 12.65 3.66 12.20 3.63 11.92 3.52 11.52 3.57 11.25 3.54
15 10 14.78 3.91 13.70 3.80 13.37 3.53 12.66 3.63 12.46 3.55
- 10 -
3-2. Heating capacity 3. Capacity table
DUCT TYPE AMUG24-48LMAS DUCT TYPE AMUG24-48LMAS

Fujitsu AOUG48LMAS1 Specifications

General

Brand	Fujitsu
Model	AOUG48LMAS1
Category	Air Conditioner
Language	English
