1. Specifications
Type
Duct
Inverter heat pump
Model name AMUG24LMAS AMUG30LMAS AMUG36LMAS AMUG48LMAS
Power supply 208/230 V ~ 60 Hz
Power supply intake Outdoor unit
Available voltage range 187—253 V
Capacity
Cooling
95 °FDB
(Outdoor temp.)
Rated
kW 7.03 8.79 10.55 13.36
Btu/h 24,000 30,000 36,000 45,600
Min.—Max.
kW 1.58—8.50 2.81—10.76 3.81—11.14 3.81—14.07
Btu/h 5,400—29,000 9,600—35,000 13,000—38,000 13,000—48,000
82 °FDB
(Outdoor temp.)
Min.—Max.
kW 3.17—9.01 3.17—11.20 3.96—12.20 3.96—15.20
Btu/h 10,800—30,700 10,800—38,000 13,500—41,700 13,500—51,800
Heating
47 °FDB
(Outdoor temp.)
Rated
kW 7.91 9.38 12.31 15.53
Btu/h 27,000 32,000 42,000 53,000
Min.—Max.
kW 1.58—9.50 2.70—11.43 3.22—15.24 3.22—15.83
Btu/h 5,400—32,400 9,200—39,000 11,000—52,000 11,000—54,000
17 °FDB
(Outdoor temp.)
Rated
kW 5.48 6.62 8.91 11.58
Btu/h 18,700 22,600 30,400 39,500
Min.—Max.
kW 1.08—6.57 1.88—8.06 2.32—11.16 2.37—11.79
Btu/h 3,700—22,400 6,400—27,500 7,900—38,000 8,100—40,200
5 °FDB
(Outdoor temp.)
Min.—Max.
kW 1.08—5.80 1.52—6.51 2.02—9.66 2.02—10.03
Btu/h 3,700—19,800 5,200—22,200 6,900—32,900 6,900—34,200
Lower limit
(Outdoor temp.)
Min.—Max.
kW 0.88—5.30 1.49—6.36 1.70—8.45 1.70—8.77
Btu/h 3,000—18,100 5,100—21,700 5,800—28,830 5,800—29,940
Input power
Cooling
95 °FDB
(Outdoor temp.)
Rated
kW
2.00
2.97 3.18 5.56
Min.—Max. 0.55—2.22 0.61—3.41 0.85—3.52 0.85—5.94
82 °FDB
(Outdoor temp.)
Min.—Max. 0.50—1.90 0.50—2.97 0.60—3.05 0.60—5.28
Heating
47 °FDB
(Outdoor temp.)
Rated 2.48 3.02 3.82 5.35
Min.—Max. 0.55—3.47 0.57—4.16 0.67—5.39 0.67—5.42
17 °FDB
(Outdoor temp.)
Rated 1.93 2.43 3.23 4.54
Min.—Max. 0.43—3.29 0.46—3.34 0.57—5.20 0.57—5.23
5 °FDB
(Outdoor temp.)
Min.—Max. 0.54—3.22 0.47—3.26 0.60—4.77 0.60—4.80
Lower limit
(Outdoor temp.)
Min.—Max. 0.48—3.20 0.42—3.24 0.59—4.28 0.59—4.30
Fan
HIGH
W
106.9 136.3 204.3 412.4
MED 67.4 96.3 63.4 118.2
LOW 50.6 57.7 42.1 73.1
QUIET 19.7 22.7 31.0 38.5
Current
Cooling
Rated A
8.8 13.0 14.0 24.4
Heating 10.9 13.3 16.8 23.5
EER Cooling
kW/kW 3.52 2.96 3.31 2.40
Btu/hW 12.0 10.1 11.3 8.20
COP Heating
kW/kW 3.19 3.11 3.22 2.90
Btu/hW 10.9 10.6 11.0 9.9
SEER Cooling
Btu/hW
19.0 18.5 18.0 17.0
HSPF Heating 10.7 10.3 10.2
Power factor
Cooling
%
98.8 99.2 98.8 99.1
Heating 98.9 98.7 98.9 99.0
Moisture removal pints/h (L/h) 4.6 (2.2) 7.2 (3.4) 9.3 (4.4)
Maximum operating current *
1
Cooling
A
15.6 32.4
Heating 16.1 32.4
Fan
Airflow rate
Cooling
HIGH
CFM (m
3
/h)
800 (1,359) 870 (1,478) 1,200 (2,039) 1,640 (2,786)
MED 670 (1,138) 730 (1,240) 740 (1,257) 1,020 (1,733)
LOW 590 (1,002) 820 (1,393)
QUIET 310 (527) 490 (833) 590 (1,002)
Heating
HIGH 800 (1,359) 870 (1,478) 1,200 (2,039) 1,640 (2,786)
MED 670 (1,138) 730 (1,240) 740 (1,257) 1,020 (1,733)
LOW 590 (1,002) 820 (1,393)
QUIET 310 (527) 490 (833) 590 (1,002)
Type × Q'ty Sirocco fan × 1
Static pressure range inWG (Pa) 0.1 to 1 (20 to 250)
Sound pressure level *
2
Cooling
HIGH
dB (A)
40 42 41 48
MED 34 37 30 36
LOW 32 33 27 31
QUIET 26 28 24 25
Heating
HIGH 37 39 40 47
MED 33 36 35 37
LOW 31 32 28 32
QUIET 25 26 29
Heat exchanger type
Dimensions (H × W × D) in (mm)
16 × 17- 2/16 × 1- 8/16
(406 × 435 × 38)
32 × 17-2/16 × 1-8/16
(813 × 435 × 38)
Fin pitch FPI 16 15
Rows × Stages 2 × 48 2 × 64
Pipe type Aluminum
Fin type Aluminum
Enclosure
Material Steel
Color ―
Dimensions
(H × W × D)
Net
in (mm)
42- 8/16 × 21 × 21- 11/16
(1,080 × 533 × 551)
57 × 21 × 21- 11/16
(1,448 × 533 × 551)
Gross
42- 12/16 × 24 × 25- 5/16
(1,086 × 610 × 643)
57- 2/16 × 23 × 26- 8/16
(1,451 × 584 × 673)
Weight
Net
lb (kg)
104 (47) 132 (60)
Gross 116 (52.5) 146 (66)
Connection pipe
Size
Liquid
in (mm)
Ø 3/8 (Ø 9.52)
Gas Ø 5/8 (Ø 15.88)
Method Flare Flare Flare Flare
Drain port Size in (mm) Ø 3/4 (19) [O.D.] Ø 3/4 (19) [O.D.] Ø 3/4 (19) [O.D.] Ø 3/4 (19) [O.D.]
- 2 -
1. Specifications
DUCT TYPE
AMUG24-48LMAS
DUCT TYPE
AMUG24-48LMAS
