Installation and operating manual “1350-EN” 41
Heat pump, Split, single service
2920 S With electrical utility lock (EX4) Locked, Released Released
Released :HP=ON _ Back-up DHW = off _ 1st back-up HP = off _ 2nd back-up HP = off _ Boiler = ON
Locked : HP = off
_ Back-up DHW = off _ 1st back-up HP = off _ 2nd back-up HP = off _ Boiler = ON
Additional generator (Boiler connection)
3700 S Release under outside temperature --- , -50 … 50 °C 0,5 °C 2°C
3705 I Time delay on stopping 0 … 120 min 1 min 20
Domestic hot water (DHW) (Only with the DWH kit option)
5020 S Overheight initial setting 0 … 30°C 1 °C 5°C
5024 S Differential 0 … 20°C 1 °C 7°C
5030 S Limitation on load duration 10 … 600 min 10 min 90 min
5060 S Electrical resistance regime Replacement, Summer,
Always, Cooling regime
Replacement
5061 S Release of electrical resistance 24h/day, Release of DHW,
Programme 4/DHW
Release of
DHW
Installation configuration
5700 I Pre-setting 1,2,3...12 1 1
This control enables you to choose one of the 8 pre-selected installation configurations. The hydraulic layouts for
the various configurations are detailed in the section: "Installation Configurations".
– Pre-setting1:1heating circuit
– Pre-setting2:1heating circuit and DHW tank.
– Pre-setting3:2heating circuits.
– Pre-setting4:2heating circuits and DHW tank.
– Pre-setting 5 : Boiler connection and 1 heating circuit.
– Pre-setting 6 : Boiler connection and 2 heating circuits
– Pre-setting 7 : Boiler connection, 1 heating circuit and DHW tank.
–
Pre-setting 8 : Boiler connection, 2 heating circuits and DHW tank.
–
Pre-setting 9 to 12 : Do not use for heat pump model "S". Reserved only for heat pump model "Duo"
5711 S Cooling circuit 1 Off, System with 4 tubes,
System with 2 tubes
Off
5870 S Combined DHW tank no, yes No
6046 I Function input H2
1 - Operating mode change HCs + DHW
2 - Operating mode change HCs
3 - Operating mode change HC1
4 - Operating mode change HC2
6 - Error/alarm message
9 - Dew point monitoring
16 - Swimming pool release
1…16 1 9
6047 I Contact type H2
NC - Normally-closed, NO - Normally-opened
NC, NO NO
6100 S Outside temperature sensor correction -3…3°C 0,1°C 0°C
6120 S Installation frost-free mode ON, Off ON
6205 S Re-initialise parameters No, yes No
6220 S oftware version (RVS) 0...99 0
Error
6711 U Heat pump Reset No, yes No
6740 S Temperature alarm initiation CC1 ---, 10… 240 min 10 min ---
Line
Function Setting range
or display
Setting
increment
Basic
setting
