OUTDOOR UNIT
AOYG07LUCA
2012.11.20 20
24 Compressor Assy 9317083034
26 3-way Valve Sub Assy 9317366038
30 Pulse Motor Valve Assy 9317216036
29 Solenoid 9970079023
23 Condenser Total Assy 9317287012
31 Expansion Valve Coil 9970103025
28 4-way Valve Assy 9317890021
25 2-way Valve Sub Assy 9317345033
21 Base Assy 9316916029
Ref. Description Part number
21
24
25
23
30
26
31
28
29
