PARTS
5
3
6
4
9
1
2
7
8
INDOOR UNIT
2012.11.19 13
8
5
9
7
6
Under Cover 9318879018
3 Bracket Panel 9318913002
1
Wire Cover 9318911015
2
Wire Shield 9318919004
4 Air Clean Filter Assy 9317250009
Remote Control 9319207018
Remote Control Holder 9318912005
Ref. Description Part number
Louver U (Upper) 9318880007
Louver Z (Lower) 9318881004
