DIMENSIONS
unit : mm
282
185
870
2011.04.22 2
INDOOR UNIT
OUTDOOR UNIT
Drain pipe diameter
16.2 mm
Liquid pipe diameter : 6.35 mm
Gas pipe diameter : 9.52 mm
540
20
660
540
19.5
29068
