PARTS
6
2
2
4
3
5
1
INDOOR UNIT
2014.01.28 11
2
6
7
5 Front Panel 9332545012
Bracket panel
1
Wire Cover 9332544008
3
Wire
shield
Remote Control 9332598001
Intake Grille (FUJITSU) 9332818017
4 Receiver Window 9332546019
8 Panel Cover 9332559002
Ref. Description Part number
Air Filter 9332549010
Louver with Shaft Cover
9333342009
7
8
