2016.11.09 17
21
Reactor Assy (AOYG07LMCE)
9900872014
21
Reactor Assy (AOYG09LMCE)
9900787028
22 PCB Holder 9332506013
23 Main PCB with Terminal (09) 9709434031
23 Main PCB with Terminal (07) 9709434147
-- Thermistor Assy 9900901011
-- Thermistor 9900880019
24 Heat Sink B 9332522006
Ref. Description Part number
OUTDOOR UNIT
AOYG07LMCE
AOYG09LMCE
23
22
23
24
21
