Item no. Part no. Part name Service part
1 9384321008 Intake grille A sub assy ♦
2 9383344008 Grille hinge (3 pcs.) ♦
3 9383342004 Air filter A ♦
4 9384307002 Casing U assy ♦
5 9357921006 Bearing B assy ♦
6 9384110008 Sirocco fan assy ♦
7 9383443008 Rubber (Vibration proof) ♦
8 9603815004 Brushless DC motor ♦
9 9384236005 Motor mount assy ♦
10 9384311009 Casing B assy ♦
11 9352173011 Cap (Power) ♦
12 9383406003 Side panel L ♦
13 9384308009 Top panel cover assy (4-fan) ♦
14 9384144003 Flap assy (4-fan) ♦
15 9384324009 Hose sub assy ♦
16 9383384004 L and R louver ♦
17 9383385001 Base (Louver) ♦
18 9900896027 Terminal (5P) ♦
19
9711524010 Main PCB (for 36 model) ♦
9711524027 Main PCB (for 45 model) ♦
20 9384312006 Box (Gear) sub assy ♦
21 9900960049 Thermistor (Room) ♦
22
9710661044 Power supply PCB (for 36 model) ♦
9710661037 Power supply PCB (for 45 model) ♦
23 9710019005 2-way remote PCB ♦
24 9306489045 Terminal (3P) ♦
25 9707457056 Reactor assy ♦
26 9384320001 Side panel R sub assy ♦
27 9900892029 Thermistor (Pipe) ♦
28 9384287007 Evaporator total assy ♦
29 9384364005 Drain pan total assy (4-fan) ♦
30 9358746004 Drain cap ♦
31 9384241009 Front panel (4-fan) assy ♦
2-3. Models: ABYG36KRTA and ABYG45KRTA - (02-7) - 2. Indoor unit parts list
