6-3. Model: AOYG14KBTB
NOTE: Values mentioned in the table are calculated based on the maximum capacity.
COOLING
Pipe length (m)
5 7.5 10 15 20 25
Height difference H (m)
Indoor unit is higher than
outdoor unit *
1
20 — — — — 0.932 0.930
15 — — — 0.953 0.950 0.947
10 — — 0.983 0.968 0.966 0.962
7.5 — 0.988 0.987 0.972 0.970 0.966
5 0.992 0.992 0.991 0.976 0.974 0.970
0 1.000 1.000 0.999 0.984 0.982 0.978
Indoor unit is lower than
outdoor unit *
2
-5 1.000 1.000 0.999 0.984 0.982 0.978
-7.5 — 1.000 0.999 0.984 0.982 0.978
-10 — — 0.999 0.984 0.982 0.978
-15 — — — 0.984 0.982 0.978
-20 — — — — 0.982 0.978
HEATING
Pipe length (m)
5 7.5 10 15 20 25
Height difference H (m)
Indoor unit is higher than
outdoor unit *
1
20 — — — — 0.891 0.862
15 — — — 0.918 0.891 0.862
10 — — 0.981 0.918 0.891 0.862
7.5 — 1.000 0.981 0.918 0.891 0.862
5 1.000 1.000 0.981 0.918 0.891 0.862
0 1.000 1.000 0.981 0.918 0.891 0.862
Indoor unit is lower than
outdoor unit *
2
-5 0.995 0.995 0.976 0.914 0.886 0.858
-7.5 — 0.993 0.974 0.912 0.884 0.856
-10 — — 0.972 0.909 0.882 0.854
-15 — — — 0.900 0.873 0.845
-20 — — — — 0.863 0.834
- 67 -
6-3. Model: AOYG14KBTB
6. Capacity compensation rate for pipe length and height difference
