7. Additional charge calculation
7-1. Model: AOYG09KBTB
Refrigerant type R32
Refrigerant amount g 850
¢ Refrigerant charge
Total pipe length m 15 or less 20 (Max.)
20 g/m
Additional charge g 0 100
7-2. Models: AOYG12KBTB and AOYG14KBTB
Refrigerant type R32
Refrigerant amount g 850
¢ Refrigerant charge
Total pipe length m 15 or less 20 25 (Max.)
20 g/m
Additional charge g 0 100 200
7-3. Model: AOYG18KBTB
Refrigerant type R32
Refrigerant amount g 1,020
¢ Refrigerant charge
Total pipe length m 20 or less 25 30 (Max.)
20 g/m
Additional charge g 0 100 200
7-4. Model: AOYG22KBTB
Refrigerant type R32
Refrigerant amount g 1,250
¢ Refrigerant charge
Total pipe length m 20 or less 25 30 (Max.)
20 g/m
Additional charge g 0 100 200
- 70 -
